Traffic Analysis for Port 10 -- Switch 3300 XM

System: Switch 3300 XM in
Maintainer: Mike Rivett
Description:RMON:10/100 Port 10 on Unit 1
ifType: ethernetCsmacd (6)
ifName:
Max Speed: 1250.0 kBytes/s

The statistics were last updated Friday, 2 July 2004 at 0:15,
at which time 'Switch 3300 XM' had been up for 263 days, 15:19:24.
`Daily' Graph (5 Minute Average)
day
Max  In: 14.4 kB/s (1.2%) Average  In: 266.0 B/s (0.0%) Current  In: 40.0 B/s (0.0%)
Max  Out: 277.4 kB/s (22.2%) Average  Out: 2726.0 B/s (0.2%) Current  Out: 56.0 B/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 3666.0 B/s (0.3%) Average  In: 120.0 B/s (0.0%) Current  In: 62.0 B/s (0.0%)
Max  Out: 159.4 kB/s (12.8%) Average  Out: 538.0 B/s (0.0%) Current  Out: 79.0 B/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 7076.0 B/s (0.6%) Average  In: 163.0 B/s (0.0%) Current  In: 138.0 B/s (0.0%)
Max  Out: 43.9 kB/s (3.5%) Average  Out: 394.0 B/s (0.0%) Current  Out: 93.0 B/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 51.0 kB/s (4.1%) Average  In: 1644.0 B/s (0.1%) Current  In: 328.0 B/s (0.0%)
Max  Out: 77.8 kB/s (6.2%) Average  Out: 832.0 B/s (0.1%) Current  Out: 101.0 B/s (0.0%)

GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
