Traffic Analysis for Port 21 -- Switch 3300 XM

System: Switch 3300 XM in
Maintainer: Mike Rivett
Description:RMON:10/100 Port 21 on Unit 1
ifType: ethernetCsmacd (6)
ifName:
Max Speed: 12.5 MBytes/s


The statistics were last updated Friday, 2 July 2004 at 0:15,
at which time 'Switch 3300 XM' had been up for 263 days, 15:19:25.
`Daily' Graph (5 Minute Average)
day
Max  In: 43.0 B/s (0.0%) Average  In: 29.0 B/s (0.0%) Current  In: 31.0 B/s (0.0%)
Max  Out: 154.0 B/s (0.0%) Average  Out: 97.0 B/s (0.0%) Current  Out: 102.0 B/s (0.0%)

`Weekly' Graph (30 Minute Average)
week
Max  In: 37.0 B/s (0.0%) Average  In: 28.0 B/s (0.0%) Current  In: 28.0 B/s (0.0%)
Max  Out: 145.0 B/s (0.0%) Average  Out: 103.0 B/s (0.0%) Current  Out: 100.0 B/s (0.0%)

`Monthly' Graph (2 Hour Average)
month
Max  In: 33.0 B/s (0.0%) Average  In: 27.0 B/s (0.0%) Current  In: 29.0 B/s (0.0%)
Max  Out: 141.0 B/s (0.0%) Average  Out: 84.0 B/s (0.0%) Current  Out: 100.0 B/s (0.0%)

`Yearly' Graph (1 Day Average)
year
Max  In: 1148.0 B/s (0.0%) Average  In: 15.0 B/s (0.0%) Current  In: 29.0 B/s (0.0%)
Max  Out: 3376.0 B/s (0.0%) Average  Out: 47.0 B/s (0.0%) Current  Out: 97.0 B/s (0.0%)


GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
