Traffic Analysis for 2 -- fw

System: fw in NOC
Maintainer: Root
Description:eth0
ifType: ethernetCsmacd (6)
ifName: Internal Link
Max Speed: 100.0 Mbits/s
Ip: 192.168.1.1 ()

The statistics were last updated Tuesday, 10 February 2004 at 0:30
`Daily' Graph (5 Minute Average)
day
Max  In: 160.4 kb/s (1.6%) Average  In: 5816.0 b/s (0.1%) Current  In: 0.0 b/s (0.0%)
Max  Out: 3001.4 kb/s (30.0%) Average  Out: 135.9 kb/s (1.4%) Current  Out: 0.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 216.9 kb/s (2.2%) Average  In: 6896.0 b/s (0.1%) Current  In: 0.0 b/s (0.0%)
Max  Out: 2894.6 kb/s (28.9%) Average  Out: 149.3 kb/s (1.5%) Current  Out: 0.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 295.8 kb/s (3.0%) Average  In: 7544.0 b/s (0.1%) Current  In: 0.0 b/s (0.0%)
Max  Out: 1930.8 kb/s (19.3%) Average  Out: 123.8 kb/s (1.2%) Current  Out: 0.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 151.0 kb/s (1.5%) Average  In: 6840.0 b/s (0.1%) Current  In: 7240.0 b/s (0.1%)
Max  Out: 551.4 kb/s (5.5%) Average  Out: 75.0 kb/s (0.7%) Current  Out: 130.1 kb/s (1.3%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
